Sleeves Series
MORSE TAPER SLEEVES
EXTENSION SOCKET WITH MS.HOLE

MORSE TAPER SLEEVES

3210
Item No. Size MS.NO.S MS.NO.T D
(mm)		 d
(mm)		 L
(mm)		 Weight
(Kg)		 Accuracy
(mm)
321030 R2กม1 2 1 18.6 12.065 92 0.1 0.015
321031 R3กม1 3 1 24.1 12.065 99 0.24 0.015
321032 R3กม2 3 2 24.7 17.78 112 0.12 0.015
321033 R4กม1 4 1 31.6 12.065 124 0.6 0.015
321034 R4กม2 4 2 31.6 17.78 124 0.5 0.015
321035 R4กม3 4 3 32.4 23.825 140 0.38 0.02
321036 R45กม1 5 1 44.7 12.065 156 1.59 0.02
321037 R45กม2 5 2 44.7 17.78 156 1.49 0.02
321038 R5กม1 5 3 44.7 23.825 156 1.36 0.02
321039 R5กม4 5 4 45.5 31.267 171 0.95 0.02
321040 R6กม1 6 1 63.8 12.065 218 3.84 0.02
321041 R6กม2 6 2 63.8 17.78 218 3.73 0.02
321042 R6กม3 6 3 63.8 23.825 218 3.85 0.02
321043 R6กม4 6 4 63.8 31.267 218 3.12 0.02
321044 R6กม5 6 5 63.8 44.399 218 1.95 0.02
Morse Taper Sleeves
3211 series

Item No.

MS.NO.S

MS.NO.T

L

L 1

D

d

L 2

L 3

3211-30-10

3

1

99

94

23.825

12.065

13.5

19

3211-30-20

2

112

17.780

5.5

22

3211-40-10

4

1

124

117.5

31.267

12.065

12.5

19

3211-40-20

2

17.780

16

22

3211-40-30

3

129.5

23.825

24

36

3211-08-50

ME80

5

228

220

80

44.399

22

48

3211-08-60

ME80

6

280

6.348

22

48

Extension Socket with MS. Hole
3212 series

Item No.

MS.NO.S

MS.NO.T

D(mm)

d(mm)

L(mm)

Accuracy

3212-1-1

1

1

20

12.065

145

0.03

3212-1-2

2

30

17.780

160

3212-1-3

3

36

23.825

181

3212-2-1

2

1

20

12.065

160

3212-2-2

2

30

17.780

175

3212-2-3

3

36

23.825

196

3212-2-4

4

48

31.267

221

3212-3-1

3

1

20

12.065

175

3212-3-2

2

30

17.780

194

3212-3-3

3

36

23.825

215

3212-3-3

3

40

23.825

215

3212-3-4

4

48

31.267

240

3212-3-5

5

63

44.399

275

3212-4-1

4

1

20

12.065

200

3212-4-2

2

30

17.780

215

3212-4-3

3

36

23.825

240

3212-4-4

4

48

31.267

265

3212-4-5

5

63

44.399

300

3212-4-6

6

85

63.348

368

0.5

3212-5-1

5

1

20

12.065

232

0.04

3212-5-2

2

30

17.780

247

3212-5-3

3

36

23.825

268

3212-5-4

4

48

31.267

300

3212-5-5

5

63

44.399

335

0.05

3212-5-6

6

85

63.348

403

0.04

3212-6-1

6

1

20

12.065

294

3212-6-2

2

30

17.780

309

3212-6-3

3

36

23.825

330

3212-6-4

4

48

31.267

355

3212-6-5

5

63

44.399

390

Solid Socket
3213 series
Item No.

MS(ME).NO.S

MS.NO.T

L

L 1

D

d

3213-20-10

MS2

1

60

56

17.780

12.065

3213-30-10

MS3

70

66

23.825

3213-30-20

2

17.780

3213-40-20

MS4

63.5

31.267

3213-40-30

3

23.825

3213-50-20

MS5

2

77

70.5

44.399

17.780

3213-50-30

3

31.267

3213-50-40

4

44.399

3213-60-30

MS6

3

110

103.5

63.348

23.825

3213-60-40

4

31.267

3213-60-50

5

44.399

3213-04-30

MS40

3

70

-

40

23.825

3213-04-40

4

31.267

3213-05-30

MS50

3

86

-

50

23.825

3213-05-40

4

31.267

3213-05-50

5

44.399

3213-06-40

MS60

4

100

-

60

31.267

3213-06-50

5

44.399

3213-07-40

MS70

4

110

-

70

31.267

3213-07-50

5

44.399

3213-08-40

MS80

4

110
-

80

31.267

3213-08-50

5

44.399

3213-08-60

6

63.348

3213-09-50

MS90

5

120

-

90

44.399

3213-09-60

6

63.348

Morse Taper Sleeves
3214 series

Item No.

MS.NO.S

MS.NO.T

L

L 1

D

d

M

Accuracy

3214-2/1

2

1

95

75

17.780

12.065

M22กม1.5

0.015

3214-3/1

3

115

94

23.825

M28กม1.5

0.02

3214-3/2

2

17.780

3214-4/1

4

1

137

117.5

31.267

12.065

M35กม1.5

0.03

3214-4/2

2

17.780

3214-4/3

3

23.825

3214-5/2

5

2

173

149.5

44.399

17.780

M48กม1.5

0.04

3214-5/3

3

23.825

3214-5/4

4

31.267

3214-6/3

6

3

240

210

63.348

23.825

M68กม1.5

0.04

3214-6/4

4

31.267

3214-6/5

5

44.399
