Drill Connecting Arbors
R8 Drill Connecting Arbors
3201
Item No.
D(mm)
L(mm)
Item No.
D(mm)
L(mm)
3201-JO
6.350
117
3201-B6
6.350
119
3201-J1
9.754
122
3201-B10
10.094
124
3201-J2S
13.940
125
3201-B12
12.065
128
3201-J2
14.199
128
3201-B16
15.733
135
3201-J33
15.850
132
3201-B18
17.780
143
3201-J6
17.170
132
3201-B22
21.793
152
3201-J3
20.599
137
3201-B24
23.825
162
3201-J4
28.550
148
3201-J5
35.890
154
Stralght Shank Drill Connecting Arbors
3202
Item No.
D
No.S
D1(mm)
mm
Inch
3202-J0
6
8
10
12
14
16
20
25
26
32
35
36
40
50
3/8
1/2
5/8
7/8
3/4
1
1-1/4
1-1/2
J0
6.350
3202-J1
J1
9.754
3202-J2
J2
14.199
3202-J3
J3
20.599
3202-J4
J4
28.550
3202-J5
J5
35.890
3202-J6
J6
17.170
3202-J33
J33
15.850
3202-B6
B6
6.350
3202-B10
B10
10.094
3202-B12
B12
12.065
3202-B16
B16
15.733
3202-B18
B18
17.780
3202-B22
B22
21.793
3202-B24
B24
23.825
7:24 Drill Connecting Arbors
3203 series
Item No.
D(mm)
d(mm)
L(mm)
M
Item No.
D(mm)
d(mm)
L(mm)
M
320330-J0
31.75
6.35
99
M12
320330-B10
31.75
10.094
104
320330-J1
9.754
106
320330-B12
12.065
108
320330-J2S
13.94
109
320330-B16
15.733
116
320330-J2
14.199
113
320330-B18
17.78
124
320330-J33
15.85
122
320330-B22
21.793
133
320330-J6
17.17
122
320330-B24
23.825
143
320330-J3
20.599
123

320330-J4
28.55
136

320330-J5
35.89
145

320340-J0
44.45
6.35
126
M16
320340-B10
44.45
10.094
132
320340-J1
9.754
133
320340-B12
12.065
136
320340-J2S
13.94
136
320340-B16
15.733
143
320340-J2
14.199
141
320340-B18
17.78
151
320340-J33
15.85
145
320340-B22
21.793
160
320340-J6
17.17
145
320340-B24
23.825
169
320340-J3
20.599
150

320340-J4
28.55
165

320340-J5
35.89
170

320350-J0
69.85
6.35
167
M24
320350-B10
69.85
10.094
170
320350-J1
9.754
175
320350-B12
12.065
174
320350-J2S
13.94
177
320350-B16
15.733
182
320350-J2
14.199
180
320350-B18
17.78
195
320350-J33
15.85
184
320350-B22
21.793
200
320350-J6
17.17
184
320350-B24
23.825
215

320350-J3
20.599
191

320350-J4
28.55
202

320350-J5
35.89
208
MORSE TAPER DRILL CHUCK ARBORS WITH TANG



3204
Art.No Size L
(mm)		 D
(mm)		 Art.No Size L
(mm)		 D
(mm)		 Art.No Size L
(mm)		 D
(mm)
320401 MS1-B10 84 10.094 320420 MS2-JT4 124 28.55 320440 MS4-B22 167 21.793
320402 MS1-B12 88 12.065 320421 MS2-JT6 107 17.17 320441 MS4-B24 177 23.825
320403 MS1-B16 94 15.733 320422 MS2-JT33 107 15.85 320442 MS4-JT2 148 14.199
320404 MS1-B18 100 17.78 320423 MS3-B10 116 10.094 320443 MS4-JT33 157 20.599
320405 MS1-JT0 80 6.35 320424 MS3-B12 120 12.065 320444 MS4-JT4 168 28.55
320406 MS1-JT1 85 9.754 320425 MS3-B16 126 15.733 320445 MS4-JT5 173 3.589
320407 MS1-JT2 91 14.199 320426 MS3-B18 134 17.78 320446 MS4-JT6 151 17.17
320408 MS1-JT3 99 20.599 320427 MS3-B22 143 21.793 320447 MS4-JT33 151 15.85
320409 MS1-JT6 94 17.17 320428 MS3-B24 153 23.825 320448 MS5-B16 184 15.733
320410 MS1-JT33 94 15.85 320429 MS3-JT0 112 6.35 320449 MS5-B18 192 17.78
320411 MS2-B10 97 10.094 320430 MS3-JT1 117 9.754 320450 MS5-B22 200 21.793
320412 MS2-B12 101 12.065 320431 MS3-JT2 123 14.199 320451 MS5-B24 210 23.825
320413 MS2-B16 107 15.733 320432 MS3-JT3 132 20.599 320452 MS5-JT3 190 20.599
320414 MS2-B18 115 17.78 320433 MS3-JT4 143 28.55 320453 MS5-JT4 201 28.55
320415 MS2-B22 124 21.793 320434 MS3-JT5 148 35.89 320454 MS5-JT5 206 35.89
320416 MS2-JT0 93 6.35 320435 MS3-JT6 126 17.17 320455 MS5-JT6 184 17.17
320417 MS2-JT1 98 9.754 320436 MS3-JT33 126 15.85 320456 MS5-JT33 184 15.85
320418 MS2-JT2 104 14.199 320437 MS4-B12 145 12.065 320457 MS-JT6 246 17.17
320419 MS2-JT3 112 20.599 320438 MS4-B16 151 15.733
        320439 MS4-B18 159 17.788
