WEDGE-TYPE HIGH-SPEED POWER CHUCKS
K54 -- WEDGE-TYPE HIGH-SPEED POWER CHUCKS
·This series chucks can be directly connected to the spindle noses of the machine tools, With nice rigidity and high accuracy.
·The chucks are effectively dust-proof and have a long-term durability.
·The chucks are suitable for precision machine of plate shaped workpiece as well as rough service ones.
Dimension parameters
Size Lmax
Axial wedge stroke 		Jaw stroke t(Dia.) JMax.drawpull Gripping force r/min
Jamming range 		Jamming range Gripping force Rec.cylinder
160 15 5 18 52 5200 12-140(160) 60(30)-140(160) P22 125
200 20 7 25 75 4700 16-180(200) 75(36)-180(200) P22 160
250 25 8.8 37 108 4000 25-230(250) 96(45)-230(250) P22 160
315 30 10.4 53 156 3300 40-280(315) 110(60)-280(315) P22 200
400 35 12.4 85 250 2800 40-370(400) 150(60)-370(400) P22 200
Characteristic parameters
Size Lmax
Axial wedge stroke 		Jaw stroke t(Dia.) JMax.
drawpull		 Gripping force r/min
Jamming range 		Jamming range Gripping force Rec.cylinder
160 15 5 18 52 5200 12-140(160) 60(30)-140(160) P22 125
200 20 7 25 75 4700 16-180(200) 75(36)-180(200) P22 160
250 25 8.8 37 108 4000 25-230(250) 96(45)-230(250) P22 160
315 30 10.4 53 156 3300 40-280(315) 110(60)-280(315) P22 200
400 35 12.4 85 250 2800 40-370(400) 150(60)-370(400) P22 200
Note:The ()on the above table is for soft chucks.
