K10 -- TWO-JAW SELF-CENTRING CHUCKS
|
 |
 |
|
| Application Recommended for processing all kinds of special comp-onents and components in special shape. Features 1.High precision short cylindrical center mounting. 2. All kinds of jaws can be provided, the jaws are two-piece ones and the top jaws are soft ones. 3. Flimsy parts are specifically engineered engineered by quenching, for greater durability and extended life. 4. High self-centring precision to the superior gripping force demands. | |
| Dimension characterstic parameters |
| Size | D1 | D2 | D3 | H | H1 | h | z-d |
| 125F | 95 | 108 | 30 | 97 | 58 | 4 | 3-M8 |
| 130F | 100 | 115 | 30 | 99 | 60 | 3.5 | 3-M8 |
| 160F | 130 | 142 | 40 | 115 | 65 | 5 | 3-M8 |
| 200F | 165 | 180 | 65 | 132 | 75 | 5 | 3-M10 |
| 250F | 206 | 226 | 80 | 146 | 82 | 5 | 3-M12 |
| 325F | 272 | 296 | 100 | 184 | 96 | 12 | 3-M16 |
| 380F | 325 | 350 | 135 | 186 | 98 | 6 | 3-M16 |
| K10short taper series have the same mountong dimensions as K11 three-jaw short tape series. |
